25
Related to Models: L1718S-SNQ/BNQ.AxxJEP for 5ms InnoLux module and
L1718S-SNQ/BNQ.AxxAEP for 5ms CPT Module
IF BOARD
1. FOR INL
ITEM Location P/N Description
790621300610R PCBA,I/F BOARD(V9),LE1730-6E0 ROHS
10 790621320600R PCBA,IF BOARD,OTHRS,LE1730-6E0
20 790621340600R PCBA,IF BOARD,SMD, LE1730-6E0
30 629030006501R PROGRAM(V9),LE1730-6E0 ROHS
50 511130001201R SOLDER BAR,Sn96.5/Ag3.0/Cu0.5(SAC305 VAC
50 511130001200R SOLDER BAR,Sn96.5/Ag3.0/Cu0.5/Ni0.06/Ge0
70 506440003800R LABEL,BLANK,YELLOW,10x4mm
ITEM Location P/N Description
790621320600R PCBA,IF BOARD,OTHRS,LE1730-6E0
10 C111,C144, 420431000260R
CAP EC 10uF 25V M,105℃ ST 5x11 RoHS
20 C101,C102, 420431010461R
CAP EC 100uF 16V M,105℃ ST 5x11(SK) RoH
30
C130,C133,C142,C145,
C105,
420432200460R
CAP EC 22uF 16V M,105℃ ST, 5x11,RoHS
40 C108, 420432210460R
CAP EC 220uF 16V M,105℃ ST 6.3x11 RoHS
50 CN101, 430631060020R WAFER 2.0mm 6P 180°,RoHS
60 CN105, 430631080130R WAFER 2x4P 2.0mm,200PHD-2*4ST RoHS
70 X101, 432008010370R XTAL 14.31818MHz 16pF HC-49US 30PPM,DIP,
80 CN103, 440819015030R CON D-SUB FEM.15P RA W/O SCREW DZ11AA1-H
ITEM Location P/N Description
790621340600R PCBA,IF BOARD,SMD, LE1730-6E0
10 Q103,Q106, 410500045210R XSTR PMBT3904 NPN 200MA,40V SOT23(PHILIP
10 410500045130R XSTR MMBT3904 NPN SOT-23(INFIN EON)RoHS
10 410500045140R XSTR MMBT3904LT1G NPN 200MA 40V SOT23(ON
20 Q102,Q105, 410500046210R XSTR PMBT3906 PNP 200MA,40V SOT23(PHILIP
20 410500046130R XSTR MMBT3906 PNP SOT-23(INFIN EON)RoHS
20 410500046180R XSTR MMBT3906LT1G PNP 200mA 40V SOT23(ON
To Next Page
