- 24 -
DATE: 2004. 6. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C201 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C202 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C203 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C204 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C205 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C206 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C207 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C208 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C209 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C210 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C211 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C212 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C213 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C214 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C215 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C216 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C217 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C218 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C219 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C220 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C221 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C222 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C223 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C224 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C225 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C226 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C227 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C228 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C229 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C230 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C231 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C232 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C233 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C234 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C235 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C236 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C237 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C238 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C239 0CC080CK11A 8PF 1608 50V 0.5 PF R/TP NP0
C240 0CC080CK11A 8PF 1608 50V 0.5 PF R/TP NP0
C241 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C243 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C244 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C245 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C246 0CC221CK41A 220PF 1608 50V 5% R/TP NP0
C247 0CC220CK41A 22PF 1608 50V 5% R/TP NP0
C248 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C249 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C250 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C251 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C252 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C253 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
DATE: 2004. 6. 08.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C403 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C405 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C406 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C407 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C408 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C409 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C410 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C411 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C412 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C413 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C414 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C415 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C416 0CC102CK41A 1000PF 1608 50V 5% R/TP NP0
C417 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C418 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C419 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C603 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C604 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C605 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C606 0CC101CK41A 100PF 1608 50V 5% R/TP NP0
C615 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C630 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C631 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C632 0CK104CK56A 0.1UF 1608 50V 10% R/TP X7R
C641 0CE107EF610 "100UF KMG,RD 16V 20% FL BULK"
C642 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C643 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C644 0CK105CD56A 1UF 1608 10V 10% R/TP X7R
C645 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C646 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C647 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
C648 0CK103CK51A 0.01UF 1608 50V 10% R/TP B(Y5
D601 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D602 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D603 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D604 0DS226009AA KDS226 TP KEC SOT-23 80V 300
D621 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
D622 0DS301109AA MMBD301LT1 TP MOTOROLA SOT23
ZD601 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD602 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD603 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD604 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
ZD605 0DZ560009GB BZT52C5V6S DIODES R/TP SOD323
U201 0IPRPGN015B GM2221-FLATRON F ENGIN GENESI
U202 0IMMRAL039A "AT49F002AN-55JI ATMEL 32P,PLC"
U202 0IZZTSZ498A
ATMEL 32P PLCC ST OTP L1730SS - L1730S
U202 0IZZTSZ510A "ATMEL 32P PLCC ST OTP L1930SS"-L1930S
U203 0IKE704200H KIA7042AP TO-92 TP 4.2 VOLT.
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
DIODEs
ICs
