LG FLATRON L1780Q

- 21 -
EXPLODED VIEW PARTS LIST
010
020
030
040
050
060
070
080
090
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
3091TKL132A CABINET ASSEMBLY, L1780UN BRAND 3090TKL109A ULTRA SLIM
3091TKL132B CABINET ASSEMBLY, L1780UN BRAND 3090TKL109A ULTRA SLIM-C/SKD
3091TKL133A CABINET ASSEMBLY, L1980UN BRAND 3090TKL110A ULTRA SLIM
3091TKL133B CABINET ASSEMBLY, L1980UN BRAND 3090TKL110A A-C/SKD
6304FLP201A
LCD(LIQUID CRYSTAL DISPLAY), LM170E02-TL01 LG PHILPS TFT COLOR 8MS,SUPER SLIM,12.8T,SXGA,LVDS
6304FLP198A LCD(LIQUID CRYSTAL DISPLAY), LM190E04-A4K2 LG PHILPS TFT COLOR 8MS,SUPER SLIM,15.5T,TN,SXGA,LVDS
3809TKL090B BACK COVER ASSEMBLY, L1780UN 3808TKL088A ULTRA SLIM
3809TKL090C BACK COVER ASSEMBLY, L1780UN 3808TKL088A ULTRA SLIM-C/SKD
3809TKL091C BACK COVER ASSEMBLY, L1980UN 3808TKL089A .
3809TKL091B BACK COVER ASSEMBLY, L1980UN 3808TKL089A A-C/SKD
3043TKK208A TILT SWIVEL ASSEMBLY, L1780UN . ULTRA SLIM
3043TKK208B TILT SWIVEL ASSEMBLY, L1780UN . ULTRA SLIM (C/SKD)
3043TKK210A TILT SWIVEL ASSEMBLY, L1980UN . ULTRA SLIM
3043TKK210B TILT SWIVEL ASSEMBLY, L1980UN . A-C/SKD
6871TST739A PWB(PCB) ASSEMBLY,SUB, L1980UN CONTROL TOTAL BRAND CL-68-L1780Q,L1980Q
6871TST739B PWB(PCB) ASSEMBLY,SUB, L1980UN MX C/SKD CONTROL TOTAL BRAND CL-68
3550TKK683A COVER, L173UPN PANEL VACUUM MOLDING
3550TKK683B COVER, L173UPN PANEL VACUUM MOLDING-C/SKD
3550TKK682A COVER, L193UPN PANEL VACUUM
3550TKK682B COVER, L193UPN PANEL VACUUM A-C/SKD
6633TZA019B INVERTER ASSEMBLY, FRONTEK FIF1742-50A 17,19INCH SLIM
or 6633TZA020A INVERTER ASSEMBLY, ALPS KUBNKM099A 4LAMP 17,19INCH SLIM
3313TL7062C MAIN TOTAL ASSEMBLY, L1780QN/L1781QN BRAND CL-68
3313TL7062D MAIN TOTAL ASSEMBLY, L1780QN/L1781QN MX C/SKD BRAND CL-68
3313TL9048A MAIN TOTAL ASSEMBLY, L1980UN BRAND CL-68
3313TL9048D MAIN TOTAL ASSEMBLY, L1980QN/L1981QN MX C/SKD BRAND CL-68
4951TKS185A METAL ASSEMBLY, FRAME MAIN L1780UN
4951TKS185B METAL ASSEMBLY, FRAME MAIN L1780UN-C/SKD
4951TKS186A METAL ASSEMBLY, FRAME MAIN L1980UN
4951TKS186B METAL ASSEMBLY, FRAME 1980UN A-C/SKD
3550TKK666A COVER, L173UPN BACK RING DECO
3550TKK666B COVER, L173UPN BACK RING DECO-C/SKD
3550TKK668A COVER, L193UPN BACK RING DECO
3550TKK668B COVER, L193UPN BACK RING DECO A-C/SKD
3551TKK552A COVER ASSEMBLY, L1780UN REAR . HINGE COVER
3551TKK552B COVER ASSEMBLY, L1780UN REAR . HINGE COVER-C/SKD
3551TKK553A COVER ASSEMBLY, L1980UN REAR . HINGE COVER
3551TKK553B COVER ASSEMBLY, L1980UN REAR . HINGE COVER A-C/SKD
3551TKK555A COVER ASSEMBLY, L1980UN FRONT . KNOB ASSY
3550TKK674A COVER, L173UPN BASE TOP .
3550TKK673A COVER, L193UPN BASE TOP DECO COVER
3550TKK681A COVER, L173UPN BASE TOP DECO
3550TKK671A COVER, L193UPN BASE TOP COVER
6850TAV002A CABLE,DVI, UL20276(7.5MM) AT 17INCHMM BLACK L1780UN,SLIM DM
4950TKA018A METAL, BASE CASTING-L1780Q
4950TKA026A METAL, BASE CASTING-L1980Q
4950TKA010A METAL, SHIELD DVI
4950TKA007A METAL, FIX FOLDING STOPPER
3550TKK676A COVER, L173UPN STAND REAR .
3550TKK675A COVER, L173UPN STAND FRONT .
3550TKK678A COVER, L173UPN BASE BOTTOM .
3550TKK672A COVER, L193UPN BASE BOTTOM COVER
3550TKK679A COVER, L173UPN SIDE STAND DECO
4814TKK294A SHIELD, REAR EMI-L1780Q
4814TKK294B SHIELD, REAR EMI A-C/SKD-L1780Q
4814TKK333A SHIELD, REAR EMISHIELD-L1980Q
4814TKK333B SHIELD, REAR EMISHIELD-C/SKD-L1980Q
6850TD9007D
CABLE,D-SUB, UL20276-9C(5.8MM) DT L1800,CORE POS400,,S/HEAD 1.8MM BLACK(9930) DELL 20.1 DM
or 6850TD9007C CABLE,D-SUB, UL20276-9C(5.8MM) DT L1800MM, CORE POS400MM BLACK(9930) L1730 DM
6866TDV004S CABLE,DVI, UL20276 AWG30 DT 1800MM BLACK(9930) LS204L DM
6634B00078A ADAPTER,AC-DC, AD-4212L 12V 3.5A SAMSUNG 42W SLIM MNT L1780UN,L1980UN
Description
Part No.
Ref. No.
