LG FLATRONL194WT - Replacement Parts List

- 22 -
DATE: 2006. 06. 01.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C502 0CC080CK11A C1608C0G1H080DT 8pF 0.5PF 50
C503 0CC080CK11A C1608C0G1H080DT 8pF 0.5PF 50
C504 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C505 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C506 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C507 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C508 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C509 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C510 0CC221CK41A C1608C0G1H221JT 220pF 5% 50V
C511 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C512 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C513 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C514 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C515 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C516 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C517 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C518 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C519 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C520 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C521 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C522 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C523 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C524 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C525 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C526 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C527 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C528 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C529 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C530 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C531 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C532 0CK473CH56A C1608X7R1E473KT 47nF 10% 25V
C535 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
C561 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C601 0CK105CD56A C1608X7R1A105KT 1uF 10% 10V
C602 0CC102CK41A C1608C0G1H102JT 1nF 5% 50V C
C603 0CE227EF638 KMG5.0TP16VB220M 220uF 20% 1
C604 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C605 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C606 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C607 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C608 0CE107EF610 KMG16VB100M 100uF 20% 16V 12
C609 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C610 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C701 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C703 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C704 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C705 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C706 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C707 0CC101CK41A C1608C0G1H101JT 100pF 5% 50V
C708 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C709 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C710 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
DATE: 2006. 06. 01.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
C711 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C712 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C713 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C714 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C715 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C716 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C717 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C718 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C719 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C720 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C721 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C722 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C723 0CC680CK41A C1608C0G1H680JT 68pF 5% 50V
C724 0CK103CK51A 0603B103K500CT 10nF 10% 50V
C725 0CK103CK51A 0603B103K500CT 10nF 10% 50V
D701 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D702 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D703 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D704 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D705 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D706 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D707 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D708 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D709 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D710 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D711 0DS226009AA KDS226 1.2V 85V 300MA 2A 4NS
D712 0DD184009AA KDS184 KDS184 TP KEC - 85V -
D713 0DD184009AA KDS184 KDS184 TP KEC - 85V -
D714 0DSON00138A MMBD301LT1G 600MV 30V - - 1.
D715 0DSON00138A MMBD301LT1G 600MV 30V - - 1.
ZD701 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD702 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD704 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD707 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD708 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD709 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD710 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
ZD720 0DZ560009GB BZT52C5V6S-(F) 5.6V 5.2TO6V
IC501 EAN30386101 FE252GH-LF(GM5726H-LF-AB) 1.
IC502 0IMMRSG036B M24C16-WMN6TP 16KBIT 2KX8BIT
IC504 0IKE704200H KIA7042AP -0.3TO15V 4.2V 400
IC601 0IPMGSG020A LD1117DT18TR 3.3TO8V 1.8V 12
IC602 0IPMGA0010A AZ1117H-3.3 4.75TO10V 3.3V 0
IC701 0IMMR00014A M24C02-RMN6TP 2KBIT 256X8BIT
IC702 0IMMR00014A M24C02-RMN6TP 2KBIT 256X8BIT
Q502 0TRDI80002A MMBT3904-(F) NPN 6V 60V 40V
REPLACEMENT PARTS LIST
CAUTION: BEFORE REPLACING ANY OF THESE COMPONENTS,
READ CAREFULLY THE SAFETY PRECAUTIONS IN THIS MANUAL.
* NOTE : S SAFETY Mark
AL ALTERNATIVE PARTS
MAIN BOARD
CAPACITORS
ICs
DIODEs
TRANSISTOR
