LG FlatronL204WT - Page 23

DATE: 2006. 06. 02.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q502 0TRDI80002A MMBT3904-(F) NPN 6V 60V 40V
Q503 0TRDI80002A MMBT3904-(F) NPN 6V 60V 40V
Q701 0TR390609FA KST3906-MTF PNP -5V -40V -40
Q702 0TR390609FA KST3906-MTF PNP -5V -40V -40
R501 0RJ2001D677 MCR03EZPJ202 2KOHM 5% 1/10W
R503 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R504 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R507 0RJ2702D677 MCR03EZPJ273 27KOHM 5% 1/10W
R508 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R509 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W
R511 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R514 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R515 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R516 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R517 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R518 0RJ2400D677 MCR03EZPJ241 240OHM 5% 1/10W
R519 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R520 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R521 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R522 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R523 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R524 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R525 0RJ0562D677 MCR03EZPJ560 56OHM 5% 1/10W
R526 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R527 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W
R529 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R530 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R531 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R533 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R551 0RJ1002D677 MCR03EZPJ103 10KOHM 5% 1/10W
R563 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R564 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R571 0RJ5601D677 MCR03EZPJ562 5.6KOHM 5% 1/10
R572 0RJ1102D677 MCR03EZPJ113 11KOHM 5% 1/10W
R573 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R574 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R601 0RJ2202D677 MCR03EZPJ223 22KOHM 5% 1/10W
R602 0RX0331K668 RSD02F4J3R30 3.3OHM 5% 2W 12
R604 0RJ5600D677 MCR03EZPJ561 560OHM 5% 1/10W
R620 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R621 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R704 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10W
R705 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R706 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R707 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R708 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R709 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R710 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R711 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10W
R712 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R713 0RJ0102D677 MCR03EZPJ100 10OHM 5% 1/10W
R714 0RJ1001D677 MCR03EZPJ102 1KOHM 5% 1/10W
R715 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R716 0RJ0000D677 MCR03EZPJ000 0OHM 5% 1/10W 1
R717 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R719 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R720 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W
R721 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
DATE: 2006. 06. 02.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R722 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R723 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R726 0RJ0682D677 MCR03EZPJ680 68OHM 5% 1/10W
R727 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R728 0RJ4700D677 MCR03EZPJ471 470OHM 5% 1/10W
R729 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R730 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R731 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
R732 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R733 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R734 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R735 0RJ0332D677 MCR03EZPJ330 33OHM 5% 1/10W
R736 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R737 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R738 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W
R739 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W
R740 0RJ0752D677 MCR03EZPJ750 75OHM 5% 1/10W
R741 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R742 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R743 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R751 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R752 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R753 0RJ4701D677 MCR03EZPJ472 4.7KOHM 5% 1/10
R761 0RJ1000D677 MCR03EZPJ101 100OHM 5% 1/10W
Q601 0TFVI80067A SI3865BDV(E3) N-CHANNEL MOSF
X501 6212AA2004F HC-49/U 14.31818MHZ 30PPM 14
LED1 0DLBE0048AA BL-HKBB533B-TRB SUPER YELLOW
C1 0CK104CK56A 0603B104K500CT 100nF 10% 50V
C2 0CK104CK56A 0603B104K500CT 100nF 10% 50V
R1 0RJ7501D677 MCR03EZPJ752 7.5KOHM 5% 1/10
R2 0RJ7501D677 MCR03EZPJ752 7.5KOHM 5% 1/10
R3 0RJ1201D677 MCR03EZPJ122 1.2KOHM 5% 1/10
R4 0RJ1201D677 MCR03EZPJ122 1.2KOHM 5% 1/10
R5 0RJ1801D677 MCR03EZPJ182 1.8KOHM 5% 1/10
SW1 6600R00004C JTP1127WEM 1C1P 15VDC 0.05A
SW2 6600R00004C JTP1127WEM 1C1P 15VDC 0.05A
SW3 6600R00004C JTP1127WEM 1C1P 15VDC 0.05A
SW4 6600R00004C JTP1127WEM 1C1P 15VDC 0.05A
SW5 6600R00004C JTP1127WEM 1C1P 15VDC 0.05A
- 23 -
RESISTORs
OTHERs
CONTROL BOARD
TRANSISTOR
