27
Disassemble the control plate
Disconnect the connectors. Remove 2 screws
Disassemble the top plate
Remove 4 pieces
44
STACKING KIT (DRYER & DRYER)
- STACKING KIT is provided in the upper dryer.
- STACKING KIT includes the stacking bracket(1), security bracket(3), bolt(1), screw(9).
1) Stacking bracket 2) Sliding pad 3) Screw 4) Machine screw
P/No.: AGF30609819
Stacking Coin
Installation Method (Dryer) - Coin Type Lower
44--11
To Next Page
