69
LOWER COVER
1.
Remove 2 screw on the lower cover.
2.
Take out of the lower cover.
COVER CABINET
1.
Open the door assembly.
2.
Remove 2 screws.
3.
Remove 4 screws from the top of cabinet cover.
4.
Disconnect the harness of door switch.
5.
Disassemble the cover cabinet.
WARNING
• When you disassemble the door switch connector,
be sure to take gloves and careful cabinet edge.
Failure to do so can cause serious injury.
