LG GD1329CES Service Manual

71
1.
Disassemble the top plate.
2.
Remove cover cabinet.
3.
Disconnect the door lamp and electrode
sensor connector.
4.
Remove 4 screws.
5.
Disassemble the tub drum front.
TUB DRUM [FRONT]
1.
Disassemble the top plate.
2.
Remove the cabinet cover and
drum front.
3.
Loosen belt from motor and idler pulleys.
4.
Carefully remove the drum.
DRUM ASSEMBLY
-1
-2
-1
