- 4 -
Copyright © 2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
4. General Specification
1. Application range
This specification is applied all of the DLP Projector FM91A
chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
1) Temperature : 25±5ºC, CST : 40±2ºC
2) Relative Humidity : 65±10%
3) Power Voltage : Standard input voltage (100-240V@50/60Hz)
* Standard Voltage of each products is marked by models.
4) Specification and performance of each parts are followed
each drawing and specification by part number in
accordance with BOM.
5) The receiver must be operated for about 30 minutes prior to
the adjustment.
3. Test method
1) Performance: LGE TV test method followed
2) Demanded other specification
- Safety: CE specification(EN55022 Class A)
- EMC:CE(EBN60950-1)
No. Item Specification Remark
Min Max Unit
1. Video input applicable system 1) NTSC M 3.579545 / 60 Hz
2) NTSC 4.43 4.433618 / 60 Hz
3) PAL-B,D,G,H,I 4.433618 / 50 Hz
4) PAL M 3.575611 / 60 Hz
5) PAL N 3.582056 / 50 Hz
6) PAL 60 4.433618 / 60Hz
7) SECAM 4.286 / 50 Hz
2. Power Adapter - DC 19.5V@4.74A
3. Input Voltage AC 100(-10%) – 240(+6%)V, 50/ 60Hz
4. Market World wide
5. Picture size 4:3
6. Aspect ratio 4:3
7. Operating Temperature 0 40 deg
8. Operating Humidity 75 %
9. Storage Temperature -20 60 deg
10. Storage Humidity 85 %
