21
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight 3.6 kg
External dimensions (W x H x D) 430 x 73 x 305 mm
Operating conditions Temperature 5°C to 35°C,
Operation status: Horizontal
Operating humidity 5% to 85%
Laser Semiconductor laser,
wavelength 650 nm
Tuner FM
FM Tuning Range 87.5 - 108.0 MHz or 65.0 - 74.0 MHz, 87.5 - 108.0 MHz
FM Intermediate Frequency 10.7 MHz
Amplifier
Stereo mode 70 W + 70 W (4Ω at 1 kHz, THD 10 %)
Subwoofer*: 160 W (3Ω at 30 Hz, THD 10 %)
Speakers
Speakers
Front Passive
Speaker Subwoofer
Type 2 Way 3 Speaker 1Way1Speaker
Impedance 4 Ω 3 Ω
Rated Input Power 70 W 160 W
Max. Input Power 140 W 320 W
Net Dimensions (W x H x D)
270 x 1103 x 270 mm 170 x 400 x 382 mm
Net Weight 3.6 kg 5.7 kg
Designs and specifications are subject to change without
prior notice.
Specifications
