5. Test & debug flow
Check the POWER PART.
NO
Check the POWER PART.
NO
YES
Check the
AC voltage Power PCBA (110V
or 220V).
Check the regulators or diode.
NO
1. Check 27MHz system clock.
2. Check system reset circuit.
3. Check FLASH R/W enable signal PRD,
RWR.
4. Check FLASH Memory related circuit.
NO
Replace FLASH.
NO
YES
Are the
DC Voltage outputs OK? (12V,
3.3V, 5V, 7V, 34V).
YES
Are 3.3V and
5V DC outputs normal on main
PCBA?
YES
YES
Update
FLASH successfully?
YES
Switch on the Power PCBA.
TEST.
A
