3. CAPACITORS ON MAIN AND AMP BOARD
4. CAPACITORS ON FRONT BOARD
No.
Capacitor
Value(uF)
Voltage
Spec.
EE Mode Playback
(+) (-) Gap Margin (+) (-) Gap Margin
C106 220 10 V 3.41 V 0 V 3.41 V 6.59 V 3.4 V 0 V 3.4 V 6.6 V
C114 100 16 V 3.4 V 0 V 3.4 V 12.6 V 3.4 V 0 V 3.4 V 12.6 V
C122 220 10 V 3.69 V 0 V 3.69 V 6.31 V 3.69 V 0 V 3.69 V 6.31 V
C124 47 16 V 4.96 V 0 V 4.96 V 11.04 V 4.95 V 0 V 4.95 V 11.05 V
C127 47 16 V 12.11 V 0 V 12.11 V 3.89 V 12.12 V -0.01 V 12.13 V 3.87 V
C133 47 16 V 3.4 V 0 V 3.4 V 12.6 V 3.4 V 0 V 3.4 V 12.6 V
C145 10 16 V 3.4 V 0 V 3.4 V 12.6 V 3.39 V 0 V 3.39 V 12.61 V
C146 100 16 V 3.24 V 0 V 3.24 V 12.76 V 3.24 V 0 V 3.24 V 12.76 V
C241 22 50 V 2.47 V 0 V 2.47 V 47.53 V 2.46 V 0 V 2.46 V 47.54 V
C243 47 16 V 4.93 V 0 V 4.93 V 11.07 V 4.92 V 0 V 4.92 V 11.08 V
C264 10 16 V 4.94 V 0 V 4.94 V 11.06 V 4.93 V 0 V 4.93 V 11.07 V
C265 10 16 V 3.24 V 0 V 3.24 V 12.76 V 3.24 V 0 V 3.24 V 12.76 V
C267 47 16 V 4.92 V 0 V 4.92 V 11.08 V 4.92 V 0 V 4.92 V 11.08 V
C268 10 16 V 2.46 V 0 V 2.46 V 13.54 V 2.46 V 0 V 2.46 V 13.54 V
C274 470 10 V 1.57 V 1.4 V 0.17 V 9.83 V 2.13 V 1.93 V 0.2 V 9.8 V
C275 470 10 V 2.29 V 2.21 V 0.08 V 9.92 V 2.29 V 2.09 V 0.2 V 9.8 V
C276 470 10 V 2.28 V 2.14 V 0.14 V 9.86 V 2.28 V 2.11 V 0.17 V 9.83 V
C282 470 10 V 1.56 V 0.89 V 0.67 V 9.33 V 2.1 V 1.41 V 0.69 V 9.31 V
C417 47 16 V 3.21 V 3.2 V 0.01 V 15.99 V 3.19 V 2.28 V 0.91 V 15.09 V
C418 47 16 V 3.21 3.2 V 0.01 V 15.99 V 3.19 V 3.02 V 0.17 V 15.83 V
C420 47 16 V 4.95 V 0 V 4.95 V 11.05 V 4.9 V 0.04 V 4.86 V 11.14 V
C421 47 16 V 4.95 V 0 V 4.95 V 11.05 V 4.91 V 0.04 V 4.87 V 11.13 V
C423 100 16 V 4.94 0 V 4.94 V 11.06 V 4.93 V 0 V 4.93 V 11.07 V
C426 47 16 V 2.02 V 0 V 2.02 V 13.98 V 2.03 V 0 V 2.03 V 13.97 V
C427 47 16 V 1.41 V 0 V 1.41 V 14.59 V 1.41 V 0.04 V 1.37 V 14.63 V
C451 47 16 V 1.89 V 0 V 1.89 V 14.11 V 1.94 V 0.04 V 1.9 V 14.1 V
C506 47 16 V 3.21 V 0 V 3.21 V 12.79 V 3.19 V 0 V 3.19 V 12.81 V
C508 47 16 V 1.84 0 V 1.84 V 14.16 V 1.9 V 0 V 1.9 V 14.1 V
C516 47 16 V 3.19 0 3.19 V 12.81 V 3.18 V 0 V 3.18 V 12.82 V
C520 47 16 V 1.34 V 0 V 1.34 V 14.66 V 1.34 0.02 1.32 V 14.68 V
C523 220 10 V 3.16 V 0 V 3.16 V 6.84 V 3.16 0 3.16 V 6.84 V
C532 100 10 V 3.17 V 0 V 3.17 V 6.83 V 3.16 V 0 V 3.16 V 6.84 V
C538 10 16 V 1.47 V 0 V 1.47 V 14.53 V 1.58 V 0 V 1.58 V 14.42 V
C549 220 10 V 3.22 V 0 V 3.22 V 6.78 V 3.22 V 0 V 3.22 V 6.78 V
C563 10 16 V 3.21 V 0 V 3.21 V 12.79 V 3.19 V 0 V 3.19 V 12.81 V
C565 10 16 V 3.21 V 0 V 3.21 V 12.79 V 3.2 V 0 V 3.2 V 12.8 V
C613 10 16 V 1.24 V 0 V 1.24 V 14.76 V 1.24 V 0 V 1.24 V 14.76 V
C648 10 16 V -0.02 V -0.06 V 0.04 V 15.96 V -0.01 V -0.03 V 0.02 V 15.98 V
C702 47 50 V 12.11 V -0.04 V 12.15 V 37.85 V 12.11 V -0.02 V 12.13 V 37.87 V
C708 10 16 V 12 V 0.01 V 11.99 V 4.01 V 12.08 V -0.03 V 12.11 V 3.89 V
C723 470 50 V 33.8 V 0 V 33.8 V 16.2 V 33.8 V 0 V 33.8 V 16.2 V
C729 470 50 V 33.8 V 16.8 V 17 V 33 V 33.8 V 16.8 V 17 V 33 V
C730 470 50 V 16.8 V 0 V 16.8 V 33.2 V 16.8 V 0 V 16.8 V 33.2 V
C731 470 50 V 16.8 V 0 V 16.8 V 33.2 V 16.8 V 0 V 16.8 V 33.2 V
C732 470 50 V 33.8 V 16.8 V 17 V 33 V 33.8 V 16.8 V 17 V 33 V
C746 470 50 V 33.8 V 0 V 33.8 V 16.2 V 33.8 V 0 V 33.8 V 16.2 V
No.
Capacitor
Value(uF)
Voltage
Spec.
EE Mode Playback
(+) (-) Gap Margin (+) (-) Gap Margin
C753 10 16 V 12.07 V -0.03 V 12.1 V 3.9 V 12.08 V -0.03 V 12.11 V 3.89 V
C768 470 50 V 33.8 V 16.8 V 17 V 33 V 33.8 V 16.8 V 17 V 33 V
C770 470 50 V 16.8 V 0 V 16.8 V 33.2 V 16.8 V 0 V 16.8 V 33.2 V
C782 470 50 V 33.8 V 16.8 V 17 V 33 V 33.8 V 16.8 V 17 V 33 V
C784 470 50 V 16.8 V 0 V 16.8 V 33.2 V 16.8 V 0 V 16.8 V 33.2 V
C785 470 50 V 33.8 V 16.8 V 17 V 33 V 33.8 V 16.8 V 17 V 33 V
C7A7 470 50 V 33.8 V 0 V 33.8 V 16.2 V 33.8 V 0 V 33.8 V 16.2 V
C7A8 470 50 V 33.8 V 0 V 33.8 V 16.2 V 33.8 V 0 V 33.8 V 16.2 V
C800 10 16 V 1.22 V 1.15 V 0.07 V 15.93 V 1.31 V 2.03 V -0.72 V 16.72 V
No.
Capacitor
Value(uF)
Voltage
Spec.
EE Mode Playback
(+) (-) Gap Margin (+) (-) Gap Margin
C229 100 16 V 11.5 V 0 V 11.5 V 4.5 V 11.49 V 0 V - -
C2A3 220 16 V 2 V 0 V 2 V 14 V 2 V 0 V - -
C2A7 1 50 V 0 V 0 V 0 V 50 V 0 V 0 V - -
C2D1 220 6.3 V 4.97 V 0.04 V 4.93 V 1.37 V 4.95 V 0 V - -
C2D3 4.7 50 V 0.56 V 0.18 V 0.38 V 49.62 V 0.5 V 0.05 V - -
C2D4 4.7 50 V 0.9 V 0.5 V 0.4 V 49.6 V 0.82 V 0.37 V - -
C309 220 6.3 V 3.33 V 0 V 3.33 V 2.97 V 3.32 V 0 V - -
C332 47 35 V 18.12 V 0 V 18.12 V 16.88 V 17.9 V 0 V - -
C333 47 35 V 0 V 0 V 0 V 35 V 0 V 0 V - -
C3A1 47 16 V 3.42 V 0 V 3.42 V 12.58 V 3.4 V 0 V - -
C3A2 47 35 V 0 V -20.6 V 20.6 V 14.4 V 0 V -20.4 V - -
