LG K1 - 1100 Display Module

71
■ 1100 Display Module
1. Remove 4 screws.
※ Remove the following parts in order before replacing this part
a. Battery Pack(1010) b. Hard Disk Drive(1020) c. Memory(1030) d. WLAN Card(1040)
e. Fan Assembly(1050) f. CPU(1060) g. ODD(1070) h. Retainer(1080) i. Keyboard(1090)
2M2.5 x L8.01SZZBZ4046A1
QtySpecificationFRU No.No.
Ch5. Removing and replacing a part
