LG L207WT - Exploded View Parts List

- 23 -
EXPLODED VIEW PARTS LIST
Copyright 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
* Note: Safety mark
200 EAJ39826101 LCD,Module-TFT, M201EW02 VC WSXGA 20.1INCH 1680X1050 300CD COLOR 92% 16/10 1000:1 AUO 20"W WCG(92%).Non-Glare, ZBD, 16.7M,Normally White mode, response time 5ms,Viewi
300 ACQ33735402 Cover Assembly, L207W . 20" Cabinet Ass'y_XG569(01-CKD)
310 MFB38581401
Lens, MOLD PMMA SAMSUNG TECHWIN LENS Lx72 / Lx7w lens , power LED Knob Double injection Power LED for L1972, Lxx7W
320 MCK38584101 Cover, MOLD ABS HF-350U L1972, Lx7W ABS L1972,LX7W PIECE DECO RING_VACUUM PLATING
330 MEY38582301
Knob, MOLD ABS HF-350U SUB TACK KNOB FOR LX7W, L1972 GLOBAL TACK, KNOB CONTROL
400 ACQ33735602 Cover Assembly,Rear, L207W . 20" Back Cover Ass'y,01-CKD
410 MGJ39028601 Plate,Metal, PRESS SPTE 0.3 SHIELD SPC L207W LAMP SHIELD
420 ADV33707206 Frame Assembly, L207W(AUO)/L227W(CMO) LM57B 20" Rear, Frame Assy
430 MCK38597501 Cover, MOLD PC+ABS L1972 ABS L1972 / L1954 / Lx7W - VESA BRACKET
440 MGJ38583701 Plate,Metal, PRESS SBHG 1.2 METAL EGI L207W PRESS SBHG 1.2 GUIDE Metal stand bracket
450 MCK38597701 Cover, MOLD PC+ABS L1972 ABS L1972 / L1954 / Lx7W - LIPS BRACKET
500 EBR38466401 PCB Assembly,Sub, CONTROL T.T LM74B L197WT-BFS AEUQQPX .
510 EAY38106001
Power Supply Assembly, AIP-0165 FREE L1954SM/L207W/L227W LCD Lienchang High Version LIEN CHANG ELECTRONIC CO. LTD.
520 EBU38495201 Main Total Assembly, L207WH-BFS BRAND LM74B
900 ACQ33707107 Cover Assembly, L1954T,L207W LM57B 20" Cover, Hinge Assy Normal Stand, 01-CKD
910 MCK38601903 Cover, MOLD ABS L1954/L207W ABS COVER, STAND BODY(01-CKD)
920 AAN33707002 Base Assembly, BASE L1954T LM57B Normal Stand Base Assy with swivel ring
930 MCK38602601 Cover MOLD ABS L1954 ABS L1954, COVER CABLE
Description
Part No.
No.
