A5
Connecting the Display
Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
Positioning your display
1. Adjust the position of the panel in various ways for maximum comfort.
Tilt Range : -3˚~17˚ Swivel :356˚
Ergonomic
It is recommended that in order to maintain an ergonomic and comfortable viewing position, the forward
tilt angle of the monitor should not exceed 5 degrees.
You do not need to replace the Locking pin after it is removed, to adjust its height.
Height Range : maximum 5 .51 inch (140.0mm)
140.0mm
* Please be sure to
remove the Locking
pin to adjust the height.
To Next Page
