2 Multi Type Air Conditioner
Multi Type Air Conditioner Installation Manual
TABLE OF CONTENTS
Safety Precautions .....3
Installation of Indoor,
Outdoor unit................6
Indoor Unit installation
......................................9
Wired Remote Controller
Installation
..................18
Wiring Connection....19
Connecting the Cable
between Indoor Unit
and Outdoor Unit ......20
Installation of
Decorative Panel.......24
Indoor Unit Drain
Piping.........................25
Air Purging and
Evacuation.................28
Test Running .............30
Optional Operation ...32
Installation guide at the
seaside ......................37
•
Connecting cable
• Four Type "A" Screw
• Hanging Bolt
(W 3/8 or M10 length 650 mm)
• Pipes: Gas side
Liquid side
• Insulated drain hose
• Additional Drain hose
Inner Dia
Cassette type............32 mm
Duct type...................25 mm
Convertible type........25 mm
•
Level
•
Screw driver
•
Electric drill
•
Hole core drill (ø70 mm)
• Flaring Tools set
• Torque Wrenches
• Hexagonal Wrench (4 mm, 5 mm)
• Gas-leak detector
•
Owner’s Manual
•
Thermometer
Installation
Requirements
Required Parts Required Tools
