Installation Manual 33
ENGLISH
2. Adjusting air volume to the height of ceiling (Cassette type)
You can choose the RPM(or air volume) of indoor motor according to the height of ceiling to
supply the comfortable atmosphere to consumers.
Procedure
1. Choose the selectable position in the table after measuring the height of ceiling.
2. In the case of changing the height as "high" or "low", open the rear cover of the wired remote-
controller.
3. Move the slide switch to the set position.
4. Close the rear cover and check if it works normally.
Optional Operation
Ceiling height Mode of slide switch Change of air volume Remark
more than 3.3 m High Ceiling Increasing
2.7~3.3 m Standard -
Manufactured in
less than 2.7 m Low Ceiling Decreasing
standard mode
