8 Multi Type Air Conditioner
Installation of Indoor, Outdoor Unit
Distributor Type (m)
Additional Refrigerant Charging Amount
Piping length and elevation
L8UC/H100BFA0
With Distributor
60 A = 30 30 15 h1=30 10
None Distributor
50 B = 50 - - h2=30 10
L8UC100BFA1
With Distributor
110 A = 50 60 30 h1=45 10
None Distributor
50 B = 50 - - h2=45 10
L8UC150BFA1
With Distributor
110 A = 50 60 30 h1=45 10
L8UC150BFE1
Total Length
Max Main Pipe
Length (A/B)
Total Branch
Pipe Length
Max Branch
Pipe Length
Max Elevation
(h1/h2)
Indoor - Indoor
Elevation (h3)
Model
48 kBtu/h Ø19.05 Ø9.52 50
Main Pipe 60 kBtu/h Ø19.05 Ø9.52 50
90 kBtu/h Ø25.4 Ø12.7 120
12/18 kBtu/h Ø12.7 Ø6.35 20
Branch Pipe 24/30/36 kBtu/h Ø15.88 Ø6.35 30
48 kBtu/h Ø19.05 Ø9.52 50
Additional
Refrigerant
(g/m)
Connecting Pipe
Diameter [mm]
Gas Liquid
To Next Page
