- 3 -
Copyright © LG Electronics Inc. All rights reserved.
Only training and service purposes.
WARNING FOR THE SAFETY-RELATED COMPONENT.
• There are some special components used in monitor that
are important for safety. These parts are marked
on the Exploded View. It is essential that these critical
parts should be replaced with the manufacturer' s
specified parts to prevent electric shock, fire or other
hazard.
• Do not modify original design without obtaining written
permission from manufacturer or you will void the
original parts and labor guarantee.
WARNING
CAUTION ELECTRIC SHOCK POSSIBLE !
• Handle the wires and connectors of the inverter. Circuit
with extreme caution. If the wires are pressed together
they can cause a short and may burn or cause a fire.
Leakage Current Hot Check Circuit
• Replaceable batteries
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY
AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
REPLACE ONLY WITH THE SAME OR EQUIVALENT
TYPE.
ADVARSEL
Lithiumbatteri - Eksplosionsfare ved fejlagtig
håndtering.
Udskiftning må kun ske med batteri af samme
fabrikat og type.
Levér det brugte batteri tilbage til leverandøren.
ATTENTION
II y a danger d’explosion s’il y a remplacement incorrect
de la batterie.
Remplacer uniquement avec une batterie du même
type ou d’un type équivalent
recommandé par le constructeur.
Mettre au rebut les batteries usagées conformément
aux instructions du fabricant.
VORSICHT
Explosionsgefahr bei unsachgemäßem Austausch der
Batterie
Entsorgung gebrauchter Batterien nach Anleitung
PRECAUTION
1.5 Kohm/10W
0.15µF
To Instrument's
exposed
METALLIC PARTS
Good Earth Ground
such as WATER PIPE,
CONDUIT etc.
When the load is 25A between Earth and 2nd Ground
for 1 second, Resistance must be less than 0.1 ohms
*Base on Adjustment standard
CAUTION
Use only an insulated screwdriver to prevent electric
shock.
