Caution for safety
Any electrical installation work must be carried out by a qualified electrician or competent person.
This electric appliance must be installed according to the instructions in order to avoid a damage.
This oven should be disconnected from the power supply before installation or maintenance. This
oven should always be earthed.
The work in the low cabinet
Oven dimensions and kichen cabinet dimensions are shown in the fig-1A, 1C, 1D.
The oven power supply must be located in the back area (P) of kitchen cabinet or outside the
installation space (cupboard).
In accordance with the position of power supply, make a hole “P ” in the back wall to pass the
connection lead.
Lift the oven and slide into the cabinet by using side holes. But do not try to lift the oven by door
handle on the front.
Take care not to kink the wires of the electrical supply cable.
If installing with hobs, follow the hob installation instruction.
