ENGLISH
The work in the high cabinet
Oven dimensions and kichen cabinet dimensions are shown in the fig-2A, 2B.
A gap must be minimum 10mm between the rear of the installed oven and the connecting wall.
To Lift oven, use side holes of the oven (refer to arrow, Fig-2A).
Kitchen cabinet in contact with the oven must be heat resistant up to 90 °C, and close units fronts
up to at least 70 °C.
[fig-2A]
[fig-2B]
[fig-2C]
