Cable Connection
B
C
A
11
Cable connection
A
Connect the telephone cord (curly cord)
to the handset and the other end to the
handset jack at the bottom of the telephone.
B Connect the line cable to the port at the
bottom of telephone and the other end to
the wall socket.
C Connect the Headphone to the headphone
jack on the left side of the telephone.
(As viewed from the front.)
※Note: 7004N and 7004D does not
support integral headphone mode.
To Next Page
