Repair Instruction
s
embly, Fan
Warning: Check the components before replacing them.
NG OK
it is necessary to check the foam location around the edges on Grille, Fan.
Grille As
s
z
er
It is necessary to check the foam location around the edges on shroud.
NG
OK
Shroud Assembly, Free
z
It is necessary to check the foam location around the edges on shroud.
e
mbly, Fan
Shroud Assembly, Fan
Full Ass
e
Make sure all corners are properly sealed
Grill Assembly, Fan
30mm30mm
Evaporator Assembly
LG(61)-FO-DI-008.07
Check position of Sheath Heater. 30mm from the Left and Right side of liner
