LG LE50 - Page 44

43
1. Remove 2 Screws.
2D2.5 X L1.01SZZBA4097A1
QtySpecificationFRU No.No.
2. Pull up the Retainer Hook using a (-) type screwdriver.
Remove the following parts in order before replacing this part.
1. Battery Pack(1010) 2. Hard Disk Drive(1020) 3. Wireless LAN Card(1030) 4. Keyboard(1040)
■ 1050 Retainer
Ch5. Removing and replacing a part
