51
1. Remove 2 Right Hinge Screws.
2
1
1D2.0 X L3.51SZZBA4023A1
3D2.0 X L5.01SZZBZ4014C2
QtySpecificationFRU No.No.
Remove the following parts in order before replacing this part.
1. Battery Pack(1010) 2. Hard Disk Drive(1020) 3. Wireless LAN Card(1030) 4. Keyboard(1040)
5. Retainer(1050) 6. Keyboard Plate(1060) 7. Display Module(1070) 8. Key Deck(1080)
9. Optical Disk Drive(1090)
■ 1100 Main Board
Ch5. Removing and replacing a part
