LG LFC20760ST/04 - 6-2 PTC AND OLP

- 15 -
6-2 PTC AND OLP
65
Shows continuity
Open
Separate PTC-Starter
from Compressor and
measure resistance
between No. 5 and 6
of PTC-Starter with a
Tester.
(Figure 1)
Observation value is
115V/60Hz : 6.8?
±20%
The resistance value
is 0 ? (short) or
(open).
Check another
electric component.
Replace OLP.
Replace PTC-
Starter.
Figure 1
Figure 2
Normal operation of
compressor is impossible
or poor.
Separate OLP from
compressor and check
resistance value between
two terminals of OLP whit a
tester.
(Figure 2)
?
