3-5 MULTI DUCT
1. Remove an upper and lower Cap by using a flat
2. Disconnect the lead wire on the botton position.
- 6 -
3-4 DISPLAY
1. To disassemble, remove the cover hinge from any door.
IMPORTANT: Before you begin,
unplug your refrigerator.
Left Door
Release the two screws from
the upper lid (1) remove it after that.
1
2.Whit a screwdriver, remove the screw from Display.
3.Unplug the connector.
screwdriver, and loosen 2 screws.
NOTE: To assemble, follow the instruction above, at
inverse order.
