LG LFC24770ST User Manual

7. TROUBLESHOOTING WITH ERROR DISPLAY
0
Ω
OFF
Other
Short
Open
Normal
Change the sensor
Replace the refrigerator
Check the Temp and
resistance (Table-1)
Result SVC Action
7-1 Freezer Sensor Error (FS E)
No
1
2
Checking flow
Check for loose connection in .CON7
Result & SVC Action
<Temperature table-1>
Temperature
-22°F / -30°C
-13°F / -25°C
-4°F / -20°C
5°F / -15°C
14°F / -10°C
23°F / -5°C
32°F / 0°C
Result
40.5 ~ 38.5 ㏀
30.5 ~ 28.5 ㏀
23 ~ 21.5 ㏀
17.5 ~ 16.5 ㏀
13.5 ~ 12.5 ㏀
10.5 ~ 9.5 ㏀
8 ~7.5 ㏀
※
The sensor is determined by
the temperature.
For example, 23㏀ indicates -4°F.
<Drawer Model>
<Swing Model>
1-. Unplug connector from CON7.
2-. Check resistance between
wires .Blue/White to Blue/White
16

LG LFC24770ST Specifications

General

Brand	LG
Model	LFC24770ST
Type	French Door Refrigerator
Total Capacity	23.7 cu. ft.
Ice Maker	Yes
Water Dispenser	Yes
Door Finish	Stainless Steel
Energy Star Certified	Yes
Width	32 3/4 inches
