REFRIGERATOR INSTALLATION
REFRIGERATOR INSTALLATION
HOW TO REMOVE AND INSTALL
REFRIGERATOR DOOR (CONT.)
2. Refrigerator Door Reinstallation
Install the right-side door first.
X Right Door
• Lower the door onto the middle hinge pin (1).
• Make sure the door is aligned with the cabinet.
• Fit the top hinge (2) over the hinge lever latch (3)
and into place. Rotate the lever (4) counterclockwise
to secure the hinge.
• Hook the tab on the door-switch side of the cover
(5) under the edge of the wire opening in the cabinet
top.
• Position the cover into place.
• Insert and tighten the cover screw (6).
1
(4)
(3)
(2)
(6)
(5)
X Left Door
• Lower the door onto the middle hinge pin (7).
• Make sure the door is aligned with the cabinet.
• Fit the top hinge (8) over the hinge lever latch (9)
and into place. Rotate the lever (10) clockwise to
secure the hinge.
• Install the grounding screw (11) and connect all the
wire harnesses (12).
• Hook the tab on the door-switch side of the cover
(13) under the edge of the wire opening in the cabi-
net top.
• Position the cover into place.
• Insert and tighten the cover screw (14).
7
(9)
(8)
(10)
(11)
(14)
(13)
(12)
