12
ţ Insert the water supply tube into the connector.
ţ Insert the tube at least 5/8 in. (15 mm) into the
connector.
ţ Hook the tab on the door-switch side of the cover
under the edge of the wire opening in the cabinet
top.
ţ Position the cover into place.
ţ Insert and tighten the cover screw.
CAUTION
1. Insert the tube until you can see only one of the lines
printed on the tube.
2. After inserting, pull the tube to ascertain that it is
secure.
3. Assemble the clip.
Correct
Incorrect
Collet
Insert Line
Clip
Tube
REFRIGERATOR INSTALLATION
