BEFORE BEGINNING
Read each step thoroughly before proceeding.
Slide the upper drawer forward until the stops
line up with the gaps in the molded upper drawer
supports. Lift the front of the upper drawer up and
pull the upper drawer out.
REQUIRED TOOLS
1. REMOVE UPPER DRAWER
CAUTION: Unplug the refrigerator power cord from the outlet.
Flat blade and
Phillips screwdriver
7
2. REMOVE LOWER DRAWER
4. REMOVE ICEMAKER COVER
INSTALLING THE ICEMAKER
3. INSTALL ICEMAKER DUCT
Fasten the icemaker duct (10 or 11) to the
fan grille using the two Phillips screws (2).
d
the freezer section on the left side of the
2
11
10
To Next Page
