LG LMC1575SB User Manual

5-5
E. DOOR ASSEMBLY / REMOVAL
1) Open the door.
2) Check door harness connector (1) disconnected that connector locate on
Upper cavity.
3) Remove screw on harness cover and remove Harness cover after remove
screw with screwdriver.(2) on base plate around lower hinge.
4) Push locker under upper hinge to left using screwdriver.
CAUTION: Be careful not to damage door seal plate by screwdriver.
5) Lift up and push the door.
NOTE:
1. After replacing the door, be sure to check that the primary switch, monitor
switch, and secondary switch operate normally.
2. After replacing the door, check for microwave energy leakage with a survey
meter. Microwave energy must be below the limit of 4 mW/cm
2
. (with a 275 ml
water load)
3. When mounting the door assembly to the oven assembly, be sure to adjust the
door assembly parallel to the chassis. If the door assembly is not mounted
properly, microwaves may leak from the clearance between the door and the
oven.
(1)
(2)
Remove door assembly
Spacer
Remove door assembly

LG LMC1575SB Specifications

General

Style	countertop
Total Capacity	1.5 cubic feet
Sensor Cooking	yes
Timer	yes
Microwave Power	1200 watts
Voltage	120 volts
Current	14 amperes

Weight and Dimensions

Depth	17 inches
Height	12.1 inches
Width	21.4 inches
Net Weight	26 pounds
