Part 2 Functions & Controls
- 30 -
Copyright ©2017 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
n ELEVATION GRILL (REMOTE CONTROLLER_Accessory)
• How to Use Remote Controller
• Main Components of Lift Grill
As for operation of Remote Controller, use it by directing the trans-
mitter part of Remote Controller to the receiver part of front panel
directly under front panel.
• Do not drop it down or into water. Or else there is worry about trou-
ble failure.
• Do not press hard the Remote Controller button with nail (ballpoint
pen or other sharp substance). Or else there is worry about trouble
failure.
• In case when obstacle such as curtain hides the signal reception
part of receiver in between the space interval, Remote Controller
operation is infeasible.
¿ Lift grill front panel assembly
¡ Bolts for installation (4 EA, P/No. 3A00255K)
¬ Instruction manual
√ Remote Controller for lift grill
To Next Page
