1. SpecificationS
Rated Power Consumption ................................ 1600W maximum (Microwave oven+Cook top lamps+Ventilation fan)
Microwave Output............................................... 1000W (IEC60705)
Frequency .......................................................... 2450 MHz ±50 MHz
Power Supply .................................................... 120 VAC, 60 Hz
Rated Current .................................................... 14 Amp. (Microwave oven+Cook top lamps+Ventilation fan)
Magnetron Cooling ............................................ Forced Air Cooling
Rectification ....................................................... Rectification Voltage Double Half-Wave
Door Sealing ...................................................... Choke System
Safety Devices ................................................... OVEN TCO 110/0
............................................................................ MGT TCO 180/60
............................................................................ Bottom TCO : 145/0
............................................................................ Fuse (20A)
............................................................................ Primary Interlock Switch
............................................................................ Secondary Interlock Switch
............................................................................ Interlock Monitor Switch
Magnetron ......................................................... 2M246 - 050GP
Cook Top Lamp ................................................. Halogen lamp ,130V,50W
Cavity Lamp ....................................................... 125 V, 30 W or 40 W
Timer ................................................................. Digital, up to 99 min. 99 sec. (in each cooking stage)
Tray ................................................................... Tempered Safety Glass
Overall Dimensions ........................................... 29
14
/16” (W) x 16
7
/16” (H) x 15
13
/16 ” (D)
Oven Cavity Size ............................................... 22 (W) x 11
5
/8” (H) x 14
5
/8” (D)
Effective Capacity of Oven Cavity ..................... 2.0Cu.ft.
Accessories ....................................................... Ownerʼs Manual & Cooking Guide, Installation Manual,
............................................................................ Exhaust Adapter, Exhaust Damper, Mounting Kit and Filter,
............................................................................ Glass Tray, Metal Rack, Rotating Ring Assembly.
SWITCH CHART
SWITCH MODE PRIMARY
INTERLOCK
SWITCH
SECONDARY
INTERLOCK
SWITCH
INTERLOCK
MONITOR
SWITCH
CONDITIONS COM
NO
COM
NO
COM
NC
DOOR OPEN OPEN OPEN CLOSE
DOOR CLOSED CLOSE CLOSE OPEN
NOTE: Use the above switch chart with wiring diagram on page 9.

LG LMVM2033SW Specifications

General

Style	over-the-range
Color	white, smooth white
Total Capacity	2 cubic feet
Sensor Cooking	yes
Child Lock	yes
Timer	yes
Microwave Power	1000 watts

Weight and Dimensions

Depth	15.875 inches
Height	16.875 inches
Width	29.875 inches
Net Weight	63 pounds
