LG LMVM2055ST Service Manual

1-1
SPECIFICATIONS
Rated Power Consumption ................................1700W maximum (Microwave oven+Cook top lamps+Ventilation fan)
Microwave Output ...............................................1100W (IEC 60705)
Frequency ..........................................................2450 MHz ±50 MHz
Power Supply .....................................................120 VAC, 60 Hz
Rated Current ....................................................14.5 Amp. (Microwave oven+Cook top lamps+Ventilation fan)
Magnetron Cooling .............................................Forced Air Cooling
Rectification .......................................................Rectification Voltage Double Half-Wave
Door Sealing ......................................................Choke System
Safety Devices ...................................................Magnetron Thermostat: Open at 145 °C ±5 °C
Close at 60 °C ±5 °C
............................................................................Oven Thermostat: Open at 110 °C ±5 °C
Close at 0 °C ±5 °C
............................................................................Fuse(20A)
............................................................................Primary Interlock Switch
............................................................................Secondary Interlock Switch
............................................................................Interlock Monitor Switch
Magnetron ..........................................................2M282J (Toshiba)
Cook top Lamp ...................................................130 V, 35 W (Halogen)
Cavity Lamp .......................................................125 V, 30 W
Timer ..................................................................Digital, up to 99 min. 99 sec. (in each cooking stage)
Tray ....................................................................Tempered Safety Glass
Overall Dimensions ............................................29
15
/16”(W)x16
7
/16”(H)x15
3
/8”(D)
Oven Cavity Size ...............................................23
1
/2”(W)x10
3
/16”(H)x14
1
/2”(D)
Effective Capacity of Oven Cavity ......................2.0 Cu.ft.
Accessories ........................................................Owner ’s Manual & Cooking Guide, Installation Manual,
............................................................................Exhaust Adapter, Exhaust Damper, Mounting Kit and Filter,
............................................................................Rotating Ring Assembly, Glass Tray, Metal Rack, Defrost Plate .
SWITCH CHART
SWITCH MODE
CONDITIONS
DOOR OPEN
OPEN OPEN CLOSE
CLOSE CLOSE OPEN
DOOR CLOSED
PRIMARY
INTERLOCK
SWITCH
SECONDARY
INTERLOCK
SWITCH
INTERLOCK
MONITOR
SWITCH
COM
NO
COM
NO
COM
NC
NOTE: Use the above switch chart with circuit diagram on page 5-1.
