130
LMVM2277ST
Blown Fuse
T-38
PROBLEM
SOLUTION
Fuse blows immediately
when door is closed.
Improper operation of
primary and secondary
interlock switches and/or
monitor switch. Check and
adjust as necessary.
Fuse blows immediately
when door is opened.
Fuse blows immediately
when
START
is pressed
with door closed.
Malfunction of high voltage
transformer circuit, including
transformer, diode,
capacitor, magnetron,
blower motor, or main board.
129
131
