LG LN Series User Manual

- 10 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) VIC 3D input proposed mode Proposed
1
640*480
31.469 / 31.5 59.94/ 60 25.125 1
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 480P)
Secondary(SDTV 480P)
2 62.938/63 59.94/ 60 50.35/50.4 1
Frame packing
Line alternative
Secondary(SDTV 480P)
(SDTV 480P)
3 31.469 / 31.5 59.94/ 60 50.35/50.4 1 Side-by-side(Full) (SDTV 480P)
4
720*480
31.469 / 31.5 59.94 / 60 27.00/27.03 2,3
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 480P)
Secondary(SDTV 480P)
5 62.938/63 59.94 / 60 54/54.06 2,3
Frame packing
Line alternative
Secondary(SDTV 480P)
(SDTV 480P)
6 31.469 / 31.5 59.94 / 60 54/54.06 2,3 Side-by-side(Full) (SDTV 480P)
7
720*576
31.25 50 27 17,18
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 576P)
Secondary(SDTV 576P)
8 62.5 50 54 17,18
Frame packing
Line alternative
Secondary(SDTV 576P)
(SDTV 576P)
9 31.25 50 54 17,18 Side-by-side(Full) (SDTV 576P)
10
720*576
15.625 50 27 21
Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 576I)
Secondary(SDTV 576I)
11 31.25 50 54 21
Frame packing
Field alternative
Secondary(SDTV 576I)
(SDTV 576I)
12 15.625 50 54 21 Side-by-side(Full) (SDTV 576I)
13
1280*720
37.500 50 74.25 19
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 720P)
Primary(HDTV 720P)
14 75 50 148.5 19
Frame packing
Line alternative
Primary(HDTV 720P)
(HDTV 720P)
15 37.500 50 148.5 19 Side-by-side(Full) (HDTV 720P)
16 44.96 / 45 59.94 / 60 74.18/74.25 4
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 720P)
Primary(HDTV 720P)
17 89.91/90 59.94 / 60 148.35/148.5 4
Frame packing
Line alternative
Primary(HDTV 720P)
(HDTV 720P)
18 44.96 / 45 59.94 / 60 148.35/148.5 4 Side-by-side(Full) (HDTV 720P)
19
1920*1080
33.72 / 33.75 59.94 / 60 74.18/74.25 5
Top-and-Bottom
Side-by-side(half)
Secondary(HDTV 1080I)
Primary(HDTV 1080I)
20 67.432 / 67.50 59.94 / 60 148.35/148.5 5
Frame packing
Field alternative
Primary(HDTV 1080I)
(HDTV 1080I)
21 33.72 / 33.75 59.94 / 60 148.35/148.5 5 Side-by-side(Full) (HDTV 1080I)
22 28.125 50.00 74.25 20
Top-and-Bottom
Side-by-side(half)
Secondary(HDTV 1080I)
Primary(HDTV 1080I)
23 56.25 50.00 148.5 20
Frame packing
Field alternative
Primary(HDTV 1080I)
(HDTV 1080I)
24 28.125 50.00 148.5 20 Side-by-side(Full) (HDTV 1080I)
25
1920*1080
26.97 / 27 23.97 / 24 74.18/74.25 32
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Primary(HDTV 1080P)
26 43.94/54 23.97 / 24 148.35/148.5 32
Frame packing
Line alternative
Primary(HDTV 1080P)
(HDTV 1080P)
27 26.97 / 27 23.97 / 24 148.35/148.5 32 Side-by-side(Full) (HDTV 1080P)
28 28.125 25 74.25 33
Top-and-Bottom
Side-by-side(half)
Secondary(HDTV 1080P)
Secondary(HDTV 1080P)
29 56.24 25 148.5 33
Frame packing
Line alternative
Secondary(HDTV 1080P)
(HDTV 1080P)
30 28.12 25 148.5 33 Side-by-side(Full) (HDTV 1080P)
31 33.716 / 33.75 29.976 / 30.00 74.18/74.25 34
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Secondary(HDTV 1080P)
32 67.432 / 67.5 29.976 / 30.00 148.35/148.5 34
Frame packing
Line alternative
Primary(HDTV 1080P)
(HDTV 1080P)
33 33.716 / 33.75 29.976 / 30.00 148.35/148.5 34 Side-by-side(Full) (HDTV 1080P)
34 56.250 50 148.5 31
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Secondary(HDTV 1080P)
35 67.43 / 67.5 59.94 / 60 148.35/148.50 16
Top-and-Bottom
Side-by-side(half)
Primary(HDTV 1080P)
Secondary(HDTV 1080P)
7. 3D Mode
7.1. HDMI 1.4b (3D supported mode automatically)

LG LN Series Specifications

General

Category	LED TV
Brand	LG
Series	LN Series
Display Type	LED
Refresh Rate	60Hz
Resolution	Full HD
Screen Size	Varies by model
HDMI Ports	Varies by model
USB Ports	1
Audio Output	Varies by model
Energy Rating	Varies by model
