7.3. RF Input(3D supported mode manually)
No. Resolution Proposed 3D input proposed mode
1 HD
1080I
720P
2D to 3D
Side by Side(Half)
Top & Bottom
2 SD
576P
576I
2D to 3D
7.4. RF Input (3D supported mode automatically)
No. Signal 3D input proposed mode
1 Frame Compatible
Side by Side(Half),
Top & Bottom
7.2. HDMI Input(1.3)
No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode
1 1280*720 45.00 60.00 74.25 HDTV 720P
2D to 3D, Side by Side(half),
Top & Bottom, Single Frame Sequential
2 1280*720 37.500 50 74.25 HDTV 720P
3 1920*1080 33.75 60.00 74.25 HDTV 1080I
2D to 3D, Side by Side(half),
Top & Bottom
4 1920*1080 28.125 50.00 74.25 HDTV 1080I
5 1920*1080 27.00 24.00 74.25 HDTV 1080P
2D to 3D, Side by Side(Half),
Top & Bottom, Checker Board
6 1920*1080 28.12 25 74.25 HDTV 1080P
7 1920*1080 33.75 30.00 74.25 HDTV 1080P
8 1920*1080 67.50 60.00 148.5 HDTV 1080P
2D to 3D, Side by Side(half),
Top & Bottom, Checkerboard,
Single Frame Sequential,
Row Interleaving, Column Interleaving
9 1920*1080 56.25 50 148.5 HDTV 1080P
No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed 3D input proposed mode
1 1920*1080 33.75 30 74.25 HDTV 1080P
2D to 3D, Side by Side(Half)*,
Top & Bottom*, Checkerboard*,
Row Interleaving, Column Interleaving
(Photo : side by Side(half), Top & Bottom)
Others - - -
640*350
720*400
640*480
800*600
1152*864
1280*1024
2D to 3D
7.5. USB Input (3D supported mode manually)
(“*” 3D supported mode manually & automatically)
