5
Install the window security bracket with a
type B screw, as shown.
Type B screw
Security
bracket
18
6
Insert the oval end of the diffuser into the
window installation kit until the locking tabs
engage. Secure in place with four of the
included screws.
Typ e A scre ws
Typ e B scre w
INSTALLATION INSTRUCTIONS
INSTALLATION IN CASEMENT STYLE WINDOWS
