LG LPC-LM440A/X - Section 2. Electrical; Tape Deck Adjustment; Tape Speed Adjustment

- 2-1 -
SECTION 2. ELECTRICAL
❏ ADJUSTMENTS
1.TAPE DECK ADJUSTMENT
DECK MODE TEST TAPE TEST POINT ADJUSTMENT ADJUST FOR
PLAY BACK MTT-114 L/R Output L/R Maximum
2.RECORD BIAS ADJUSTMENT
DECK MODE TEST TAPE TEST POINT ADJUSTMENT ADJUST FOR
AUTO-RVS 75KHz±5KHz
AUTO-STOP 65KHz±5KHz
3.TAPE SPEED ADJUSTMENT
DECK MODE TEST TAPE TEST POINT ADJUSTMENT ADJUST FOR
PLAYBACK MTT-111 L/R Output 3kHz±50Hz
Azimuth adjusting screw
SR490
REC MODE MTT-5511
C465 OR C415(DECK
CIRCUIT B- POINT)
L405
