16 INSTALLATION
Pull the drawer open to full extension.
Gently lift and pull out the ice bin.
Grasp the drawer on each side and hook the
drawer supports into the rail tabs located on
both sides.
Lift the front of the drawer up, then pull it
straight out.
Hold both rails and push them in
simultaneously.
Remove the Durabase basket from the rails.
Remove the screws from the rails at both
ends.
Pull out both rails simultaneously, until they
are fully extended.
Grip both sides of the drawer and pull it up to
remove it from the rails.
1
2
2
3
6
4
1
5
CAUTION
• Do not hold the handle when removing or
replacing the drawer. The handle may come o,
causing personal injury.
Assembling the Freezer Drawer
