17INSTALLATION
ENGLISH
Lower the door into its nal position and
insert the screws in the rails on both sides.
Replace the ice bin in the drawer. Insert the
Durabase basket in the rail assembly.
Insert the drawer into the frame, and push
the drawer back until it clicks into place.
Make sure that the plastic sleeve is inserted in
the bottom of the door. Lower the door onto
the middle hinge pin.
Align the door with the cabinet.
Fit the hinge over the hinge lever latch
and slot it into place. Rotate the lever
counterclockwise to secure the hinge
Replace the hinge cover . Insert and tighten
the cover screws .
3
5
4
1
2
3
4
CAUTION
• Do not hold the handle when removing or
replacing the drawer. The handle may come o,
causing personal injury.
Assembling the Refrigerator Door
