LG LRFC25750ST - DISASSEMBLY; DOOR

3-1 DOOR
● Refrigerator Door
1. Remove the hinge cover by pulling it upwards.
2. Loosen the hex head bolts attaching the upper hinge to
the body and lift the freezer door.
3. Pull out the door gasket to remove from the door foam
assembly.
● Freezer Door
1. Loosen the hex head bolts attaching the lower hinge to
the body to remove the refrigerator door only.
2. Pull out the door gasket to remove from the door foam
assembly.
3. DISASSEMBLY
- 5 -
HINGE
HINGE COVER
Figure 1
GASKET
Figure 2
LOWER HINGE
BOLT
Figure 3
