LG LRFD22850ST - 3-2 TO REMOVE THE DISPENSER

2. Insert gasket into channel
1) Snap gasket assembly into the door bracket.
<Inserting the Gasket Assembly into the Bracket Door>
2) Press gasket into channels on the three remaining
sides of door.
3. Replace door frame cover
Starting at top of cover and working down, snap cover
back into door.
3-2 TO REMOVE THE DISPENSER
1. Use fiat tip screwdriver to pry back hooks on botton
underside of cover dispenser.
2. Pry off cover dispenser.
Disconnect wire harness.
3. Replace cover dispenser in opposite manner and order
of removal.
- 6 -
Figure 6
Correct
Incorrect
Figure 7
Figure 9
Figure 10
Figure 8
