17INSTALLATION
ENGLISH
from the freezer drawer, there is sufficient space
for a small child or pet to crawl inside.
1 Pull the drawer open to full extension.
2 Gently lift and pull out the ice bin.
3 Lift the front of the drawer up, then pull it
straight out.
4 Remove the Durabase basket from the rails.
Remove the screws from the rails at both
ends.
5 Grip both sides of the drawer and pull it up to
remove it from the rails.
• Do not hold the handle when removing or
replacing the drawer. The handle may come off,
causing personal injury.
6 Hold both rails and push them in
simultaneously.
Assembling Freezer Drawers
1 Pull out both rails simultaneously, until they
are fully extended.
2 Grasp the drawer on each side and hook the
drawer supports into the rail tabs located on
both sides.
To Next Page
