REPLACING THE REFRIGERATOR DOOR

REPLACING THE FREEZER DOOR

Fig. 8

Fig. 9

Fig. 10

Fig. 11

REVERSING DOORS

CAUTION

TOOLS NEEDED

REVERSING THE FREEZER DOOR

Fig. 12

Top Hinge

Fig. 13

Lower the door onto the bottom hinge pin. Place the hinge

pin of the middle hinge bracket inside of the hinge pin insert

on top of the door. Hold the door in place and line the middle

hinge bracket with the holes in the refrigerator housing.

Fig. 7

Use the two bolts and phillips screwdriver to refasten the

middle hinge bracket and door to the refrigerator housing.

Set the freezer door onto the Middle Hinge pin.

Place the upper hinge pin in the top of the freezer door and

line up the upper hinge with the holes on top of the

refrigerator. Use the three bolts to replace the hinge.

Carefully force-fit the top hinge cover back into place over

the hinge.

Remove food and any Adjustable Shelves or Door Bins

from doors. Failure to do so could result in serious injury.

for bottom door hinge).

Gently pry off the top hinge cover with a flat head screw-

driver and remove.

three bolts and lift off the top hinge. Set parts aside.
