Parts List(Outdoor)

430410 BASE ASSY,WELD[OUTDOOR] 3041AR2415E 3041AR2415E 3041AR2415E 3041AR2415E 3041AR2415E R

435511 COVER ASSEMBLY,CONTROL(OUTDOOR) 4994AR3492B 4994AR3492B 4994AR3492B 4994AR3492B 4994AR3492B R

437210 GRILLE ASSEMBLY,FRONT(OUTDOOR) 3531AR2512R 3531AR2512R 3531AR2512R 3531AR2512R 3531AR2512R R

437212 PANEL ASSEMBLY,REAR(OUTDOOR) 3530AR0058B 3530AR0058B 3530AR0058B 3530AR0058B 3530AR0058B R

546810 MOTOR ASSEMBLY,OUTDOOR 4681A20068A 4681A20068A 4681A20068A 4681A20068A 4681A20068A R

550140 ISOLATOR,COMP 4H00982E 4H00982E 4H00982E 4H00982E 4H00982E R

552102-1 TUBE,CAPILLARY BEND 5424AR3582C 5424AR3582C 5424AR3582C 5424AR3582C 5424AR3582C R

552102-2 TUBE,CAPILLARY BEND - - - - - R

552111 TUBE ASSY,CAPILLARY 5211A30337A 5211A30337A 5211A30337A 5211A30337A 5211A30337A R

552203-1 VALVE,SERVICE 2H02479F 2H02479F 2H02479F 2H02479F 2H02479F R

552203-2 VALVE,SERVICE 2A00393U 2A00393U 2A00393U 2A00393U 2A00393U R

554031 CONDENSER ASSEMBLY,BENT 5403AR2870P 5403AR2870P 5403AR2870H 5403AR2870H 5403AR2870H R

554160 COMPRESSOR 5416A20013J 5416A20013J 5416A20013J 5416A20013J 5416A20013J R

559010 FAN ASSEMBLY,PROPELLER 5900AR1266A 5900AR1266A 5900AR1266A 5900AR1266A 5900AR1266A R

567502 O.L.P 6750A30001D 6750A30001D 6750A30001D 6750A30001D 6750A30001D R

649950 CONTROL BOX ASSEMBLY,OUTDOOR 4995AR2566E 4995AR2566E 4995AR2566E 4995AR2566E 4995AR2566E R

W0CZZ CAPACITOR,DRAWING 6120AR2194G 6120AR2194G 6120AR2194G 6120AR2194G 6120AR2194G R

DESCRIPTION

PART No.

REMARKS

LS-Q082BAM LS-Q082AAL LS-Q082ACG LS-Q082ACL LS-Q082ACM

NOTE)

Please ensure GCSC since these parts may be changed depending upon the buyer's request.

(GCSC WEBSITE http://biz.LGservice.com)

LOCATION

No.
