REFRIGERATOR INSTALLATION
If the freezer compartment door is higher than the
refrigerator compartment door, level them by inserting a
flat blade screwdriver into the groove of the right leveling
leg and rotating it clockwise.
AFTER LEVELING THE DOOR HEIGHT
Confirm all legs are in contact with the floor.
Using a ¾” (19 mm) wrench, turn the keeper nut clockwise to
lossen the keeper nut.
Using a 5/16” (8 mm) wrench, turn the adjustment hinge pin
c refrigerator clockwise or ounterclockwise to level the and
After leveling the door, turn the keeper nut counterclockwise
to tighten.
freezer door.
DOOR ALIGNMENT
Remove the base grille before adjusting the doors.
See BASE GRILLE INSTALLATION for reference.
Two methods of door alignment are available based on
the amount of adjustment needed and installation
requirements.
Type 1
Adjusting tool: Flat blade screwdriver
If the freezer compartment door is lower than the
refrigerator compartment door, level them by inserting a
flat blade screwdriver into the groove of the left leveling
leg and rotating it clockwise.
Type 2
Adjusting tools:
(19 mm)
5/16” and
¾” wrench
(8 mm) wrench
CAUTION: Do not overtight the door adjustment screw.
The hinge pin can be pulled out. (Adjustable range of
height is a maximum of ½” (1.27 cm)).
Left leveling
leg
Height
difference
difference
Height
difference
Height
Right leveling leg
Height
difference
Height
difference
difference
Height
Adjustment
hinge pin
Down
Keeper nut
Wrench
