LG LSN120HSV5 Installation Manual

10
Multi F Standard Wall-Mounted Indoor Unit
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
MAX
MUL
TI
F
MULTI
F
Unit Model Number
Nominal Capacity
Cooling (Btu) Heating (Btu)
LMN079HVT 7,000 8,100
LMN159HVT 14,300 15,600
LMN249HVT 24,000 25,600
LSN090HSV5 9,000 10,900
LSN120HSV5 12,000 13,600
LSN180HSV5 18,000 21,600
Table 1: Multi F Standard Wall-Mounted Indoor Units.
INTRODUCTION
Included Parts
Part Quantity Image
Installation Plate One (1)
Type “A” Screws Five (5)
Type “B”, “C”, and “D”
Screws
(Example image;
appearances will vary)
Two (2)
Each Type
Wireless
Controller with Holder
AKB74955602
One (1)
Connectors
(For use with Multi F
Systems)
One (1) Each for 3/8 inch ĺ  1/2 inch
One (1) Each for 5/8 inch ĺ  1/2 inch
One (1) Each for 1/4 inch ĺ  3/8 inch
(All three connectors listed above are included
with the 18,000 Btu/h indoor unit;
the 3/8 inch ĺ  1/2 is the only one required
for the 24,000 Btu/h indoor unit.)
7,000 ~ 15,000 Btu/h Indoor Units
18,000 and 24,000 Btu/h Indoor Units
