Buyer Model (Indoor Unit / Outdoor unit)
Unit
LA-240HSV4 (LAN240HSV4 / LAU240HSV4)
Factory Model (Indoor Unit / Outdoor unit) AS-W243CRB6 (ASNW243CRB6 / ASUW243CRB6)
Cooling Capacity (Min ~ Rated ~ Max)
kW 0.90 ~ 6.45 ~ 8.80
Btu/h 3,070~22,000~30,030
Heating Capacity (Min ~ Rated ~ Max)
kW 0.90 ~ 8.09 ~ 11.40
Btu/h 3,070~27,600~38,898
Maximum Heating Capacity
Outdoor 17ºF (Indoor 70ºF) Btu/h 22,498 (82%)
Outdoor 5ºF (Indoor 70ºF) Btu/h 19,097 (69%)
Outdoor -4ºF (Indoor 70ºF) Btu/h 18,424 (67%)
Power Input Cooling / Heating W 2,040 / 2,670
Running Current Cooling / Heating A 7.9 / 10.7
Starting Current Cooling / Heating A 7.9 / 10.7
EER - 10.78
SEER - 20.00
COP - 3.03
HSPF (Ⅳ / Ⅴ) a) - 10.00 / 8.70
Power Supply Ø / V / Hz 1 / 208-230 / 60
Power Factor % 98.2
Air Flow Rate
Indoor,Max/H/M/L 735 (20.8) / 622 (17.6) / 509 (14.4) / 399 (11.3)
Outdoor,Max 2,119 (60)
Moisture Removal l/h (pts/h) 5.5 (2.6)
Sound Level
Indoor,H/M/L/SL (Cooling) dB(A)+3 45 / 40 / 35 / 29
Indoor,H/M/L (Heating) dB(A)+3 45 / 40 / 35
Outdoor,Max dB(A)+3 53
Compressor
Type - Twin Rotary
Model - GJT240MBA
Motor Type - Brushless DC Motor
Oil Type - PVE (FVC68D)
Oil Charge cc 900
O.L.P. name - -
Fan(Indoor)
Type - Cross Flow Fan
Motor Output W 30
Fan(Outdoor)
Type - Propeller
Motor Type - BLDC
Motor Output W 124
Circuit Breaker* A 25
Power Supply Cable No. × AWG 3 × 12
Power and Transmission Cable No. × AWG 4 × 18
Piping Connections
Liquid Side in (mm) Ø 3/8 (9.52)
Gas Side in (mm) Ø 5/8 (15.88)
Drain Hose(O.D , I.D.) in (mm) 27/32, 5/8 (21.5, 16.0)
Dimensions
Indoor (W × H × D)
mm 1,030 × 325 × 245
inch 40-9/16 × 12-13/16 × 9-11/16
Outdoor (W × H × D)
mm 870 × 800 × 320
inch 34-1/4 × 31-1/2 × 12-19/32
Net Weight
Indoor lbs (kg) 32.0 (14.5)
Outdoor lbs (kg) 120.2 (54.5)
Gross Weight
Indoor lbs (kg) 38.6 (17.5)
Outdoor lbs (kg) 130.1 (59.0)
Operation Range
Cooling (Outdoor) ℉(℃) DB 14 [0*] ~ 118 (-10 [-18*] ~ 48)
Heating (Outdoor) ℉(℃) WB -4 ~ 65 (-20 ~ 18)
Refrigerant & Charge oz (g) R410A / 63.5 (1,800)
Additional Refrigerant Charge oz/ft (g/m) 0.38 (35)
Piping Length (Min/Max) ft (m) 9.84 (3) / 98.4 (30)
Chargeless ft (m) 24.6 (7.5)
Max. Elevation Difference ft (m) 49.2 (15)
Tool Code(Chassis) Indoor + Outdoor SC + UE1+
Functions
Temperature Control Thermistor
Allergy free filter -
Plasma Filter -
Prefilter (Washable/Anti-fungus) O
3M Multi Protection filter O
Auto Clean O
CHAOS Wind(Auto Wind) O
Steps, Fan/Cool/Heat 6 / 6 / 6
Airflow Direction Control(Up& Down) Auto
Airflow Direction Control(Left & Right) Auto
Remote Controller Type Wireless LCD
Setting Temperature Range
Cooling[℉ (℃)] 64~86 (18~30)
Heating[℉ (℃)] 60~86 (16~30)
Auto Operation (Micom Control) -
Auto Changeover (Micom Control) O
Self Diagnosis O
Timer 24h, On/Off
Sleep Operation O
Soft Dry Operation O
Restart Delay (Minute) 3
Deice Control (Defrost) O
Hot Start O
Jet Cool / Jet Heat O
Low Ambient Operation O
Special Function Water Level sensor, Cooling Only switch, WIND BAFFLE
